Name: Milled Tooth 16 Inch Tricone Rotary Drill Bits IADC 617
Brand: Milled Tooth 16 Inch Tricone Rotary Drill Bits IADC 617
SKU: Milled Tooth 16 Inch Tricone Rotary Drill Bits IADC 617
Rating: 4.8 (130 reviews)

Home > products > Tricone Drill Bit >

Milled Tooth 16 Inch Tricone Rotary Drill Bits IADC 617

IADC 617 Tricone Rotary Drill Bits

16 Inch Tricone Rotary Drill Bits

Milled Tooth Tricone Rotary Drill Bits

Place of Origin:

Hebei,China

Certification:

ISO9001

Request A Quote

Milled Tooth 16 Inch Tricone Rotary Drill Bits IADC 617

Product Details

Formation:

Soft

Seal Type:

Metal Face Seal

Gauge:

With Gauge Trimmer

Sealed Type:

Rubber Sealed Bearing

Rotation Speed:

150-250 RPM

Teeth:

Milled Teeth

Main Market:

America,Europe,Africa,etc.

Warranty:

1 Year

Color:

As Your Request

Payment & Shipping Terms

Price

Negotiable

Packaging Details

According to customer needs

Delivery Time

5-15work days

Payment Terms

T/T

Supply Ability

50000PCS/Month

244.5mm Mining Rock Mill Tooth Drill Bit 9 5/8 Inch

Get Best Price

Size 558.8mm 22 Inch Tri Cone Rock Bit IADC 635

Get Best Price

311mm 12 1/4 Inch Tricone Rock Roller Bits IADC 617

Get Best Price

Advanced 660.4mm 26 Inch Tricone Drill Bits For HDD

Get Best Price

Contact Now

Product Description

Sliding shear is also an important cutting method for three cone drill bits. When the drill bit is drilling into high plastic rock layers, its cutting structure will produce relative sliding relative to the teeth. This sliding causes the cutting teeth of the drill bit to come into contact with the rock at a certain point in the wellbore, and its rotational speed is less than the revolution speed, resulting in shear fragmentation. Due to the fact that the shear strength of rocks is usually lower than their compressive strength, the efficiency of shear rock breaking is often greater than that of impact rock breaking. In addition, sliding shear can be more effectively achieved by designing super top, complex cone, and shifting axis for the cone bit body.

PRODUCT SPECIFICATIONS
product name	16 inch CR617G TCI tricone bit
size	16inch,406.4mm
model number	CR617 with Chisel tooth
series	CR
tooth type	TCI
connection	75/8"Reg PIN
bearing	rubber sealed journal bearing
Nozzle	three jet nozzles
application	water well,oil well,HDD,exploration,etc
weight	230kg
certificate	A7-1,SY/T5164,ISO9001:2008
RECOMMENDED ROCK FORMATION
medium hard with high compressive strength and stick&hard stringers,such as hard shale,limestone,sandstone and dolomite,etc.
RECOMMENDED DRILLING PARAMETERS FOR APPLICATION
Type&IADC code	417	437	447	517,527	537,547	617,627	637,647	737,837
WOB(KN/mm)	0.35~0.90	0.35~0.95	0.35~1.00	0.35~1.05	0.35~1.05	0.35~1.05	0.70~1.20	0.70~1.20
RPM(r/min)	140~70	140~60	140~60	120~50	110~40	80~40	70~40	70~40

Company Profile

Crossing Bit, a leading manufacturer of PDC bits and tricone bits in northern China, has exported its high-quality drill bits to more than 30 countries, demonstrating its strong market influence and exceptional product strength.

Crossing Drilling Tools has not only established a sterling reputation in the drilling, construction, HDD (horizontal directional drilling), exploration, water well, geothermal, mining, and oil & gas industries, but has also gained widespread recognition from customers for its exceptional product reliability and quality. We are committed to developing and producing a range of high-quality tools, including tricone bits, PDC bits, tricone cutters (single rollers), PDC reamers, drag bits, and HDD hole openers, to meet the diverse needs of our customers.

Our meticulously designed PDC bits are specifically optimized for directional drilling. With exceptional stability, durability, and "directional" friendliness, they are able to precisely maintain the bit's position in narrow and complex pay zones, ensuring smooth drilling operations.

This unique steerable bit technology, combined with high ROP (rate of penetration), sets Crossing Bit apart from the competition and establishes it as a leader in the industry.
