High Performance 5 Blades Steel Body PDC Drill Bit for Oil Well Drilling
The core component is polycrystalline diamond composite sheet - sintering diamond micro powder and hard alloy substrate together under high temperature and high pressure, which has both the ultra-high hardness of diamond and the toughness of hard alloy, like installing "diamond claws" on drill bits.
The drill bit itself is integrated and has no moving parts. It mainly consists of a joint, drill body, cutting teeth, nozzle, chip groove, and retaining teeth.
Its rock breaking principle is similar to a "scraper" - under the action of drilling pressure and torque, diamond cutting teeth penetrate the formation, cutting and scraping off the rock like a knife cutting butter, with much higher efficiency than traditional roller bits. The rock fragments are in large chunks and are carried out of the well by mud.
Fast drilling speed: Efficiency is at least 60% higher than ordinary alloy drill bits
Long lifespan: The service life can reach 10-30 times that of ordinary alloy drill bits
Widely applicable: It can be used for oil and gas drilling, shale gas development, geological exploration, and mining
PDC drill bits are most suitable for soft to medium hard formations (drillability levels of about 1-9), and are not suitable for larger gravel layers and extremely hard formations. In addition, it has weaknesses such as poor thermal stability and strong brittleness, and cannot withstand large impact loads.
|
PRODUCT SPECIFICATIONS
|
|
product name
|
5 1/2 inch CM1305 matrix body PDC bit
|
|
size
|
5 1/2 inch,139.7mm
|
|
model number
|
CM1305
|
|
series
|
CM
|
|
body type
|
matrix body
|
|
primary cutter size
|
13mm
|
|
number of nozzle
|
5
|
|
number of blade
|
5
|
|
Make Up Torque(KN.m)
|
10.4~11.4
|
|
application
|
water well,oil well,HDD,exploration,etc
|
|
weight
|
23kg
|
|
certificate
|
SY/T5164,ISO9001:2008
|
|
ROCOMMENDED ROCK FORMATION
|
|
soft to medium formation with lower compressive strength and good drillability,such as marl,shale,lignite,sandstone,anhydrite,tuff ,etc.
|
|
RECOMMENDED OPERATING PARAMETERS
|
|
Rotary Speed(RPM)
|
60~250
|
|
Weight On Bit(WOB)
|
5~45
|
|
Max.WOB(KN)
|
80
|
|
Flow Rate(lps)
|
10~25
|
Company Profile
Crossing Drilling Tools has not only established a sterling reputation in the drilling, construction, HDD (horizontal directional drilling), exploration, water well, geothermal, mining, and oil & gas industries, but has also gained widespread recognition from customers for its exceptional product reliability and quality. We are committed to developing and producing a range of high-quality tools, including tricone bits, PDC bits, tricone cutters (single rollers), PDC reamers, drag bits, and HDD hole openers, to meet the diverse needs of our customers.
Our meticulously designed PDC bits are specifically optimized for directional drilling. With exceptional stability, durability, and "directional" friendliness, they are able to precisely maintain the bit's position in narrow and complex pay zones, ensuring smooth drilling operations.
This unique steerable bit technology, combined with high ROP (rate of penetration), sets Crossing Bit apart from the competition and establishes it as a leader in the industry.
